BSWA 308S / 309S

Octave-band sound level meters from BSWA: BSWA 308S (Class 1) and BSWA 309S (Class 2), with data logging, statistics and 1/1 octave analysis.

BSWA 308S / 309S
BSWA 308S and BSWA 309S are integrating sound level meters with 1/1 octave analysis. The BSWA 308S is Class 1, for legal, environmental and laboratory measurements; the BSWA 309S is Class 2, for workplace surveys, product checks and routine noise measurement. Both follow IEC 61672-1:2013. Compared with the earlier BSWA 308/309, the new models use a single ARM processor with a floating-point unit instead of the previous dual-core (DSP + ARM) design, and all calculations are now floating point. This improves accuracy and stability, while a redesigned analogue front end lowers the noise floor and widens the linear range. Each meter measures three profiles at the same time with different frequency and time weightings, records LN statistics and time history, and stores data on a microSD card (8 GB in the current version). A mini thermal printer and an internal GPS module are available as options. เครื่องวัดเสียง BSWA 308S (Class 1) และ BSWA 309S (Class 2) วัดระดับเสียง ค่า Leq สถิติ LN และวิเคราะห์ 1/1 Octave สำหรับงานตรวจวัดเสียงสิ่งแวดล้อม เสียงในโรงงาน และตรวจคุณภาพผลิตภัณฑ์

Key features

  • Class 1 (BSWA 308) or Class 2 (BSWA 309)
  • IEC 61672-1:2013, ANSI S1.4 and ANSI S1.43
  • Real-time 1/1 and 1/3 octave (option)
  • Single range covering about 122–123 dB dynamic range
  • 3 measurement profiles in parallel, 14 user-defined measurements
  • LN statistics, Lden/Ldn and time history
  • Automatic 24 h measurement with timer
  • MicroSD storage, USB, RS-232, AC/DC outputs
  • Options: GPS timing, printer, auto power-on

Specifications

MODELS
BSWA 308Class 1 (Group X)
BSWA 309Class 2 (Group X)
BSWA 309 (CLASS 2) MAIN SPECIFICATIONS
StandardsIEC 61672-1:2013, IEC 60651, IEC 60804, ANSI S1.4-1983, ANSI S1.43-1997
MicrophoneMPA309T 1/2" prepolarised, Class 2, 40 mV/Pa, 20 Hz–12.5 kHz
Microphone interfaceTNC with ICCP (4 mA)
Frequency response20 Hz–12.5 kHz
Level linearity range25–136 dB(A); octave 33–136 dB
Dynamic range122 dB (14–136 dB(A))
Upper limit136 dB(A); 154 dB(A) with a 5 mV/Pa microphone
Peak C range50–139 dB
Self-noise20 dB(A), 26 dB(C), 31 dB(Z) (acoustic)
Frequency weightingA, B, C, Z in parallel
Time weightingF, S, I and Peak in parallel
Resolution and sampling24 bit, 48 kHz
Integration period1 s–24 h or infinite; repeat 1–9999
MEASUREMENTS
BasicSPL, Leq, Max, Min, Peak (A/B/C/Z, F/S/I)
Statistical (option)Leq1s, LIeq, SD, SEL, E, Lday, Levening, Lnight, Ldn, Lden, LN 1–99
Logger step (option)0.1 s, 0.2 s, 0.5 s, 1 s–24 h
OCTAVE ANALYSIS (OPTION)
1/1 octaveClass 1 8 Hz–16 kHz, Class 2 16 Hz–8 kHz
1/3 octaveClass 1 6.3 Hz–20 kHz, Class 2 16 Hz–12.5 kHz
StandardsIEC 61260-1:2014, ANSI S1.11-2004
DATA, DISPLAY AND OUTPUTS
Display160 × 160 LCD, white backlight
Storage8 GB microSD; read directly as a USB disk
SoftwareVA-SLM post-processing and reporting
OutputsAC, DC (10 mV/dB), RS-232, USB
Alarmuser-defined threshold with LED
Setup templates5
POWER AND PHYSICAL
Power4 × AA batteries (about 10 h), external DC 7–14 V or USB 5 V
Operating conditions-10 to 50 °C, 20–90% RH
Size70 × 300 × 36 mm
Weightabout 620 g with batteries
LanguagesEnglish, Chinese, Portuguese, Spanish, German, French
OPTIONS AND ACCESSORIES
GPS module with GPS timing
Calibrator CA111, Class 1, 94/114 dB at 1 kHz
Mini thermal or dot-matrix printer (RS-232)
Extension cable and BM200A/B 2 m microphone boom

Downloads

Measurement screens

Measurement screens

Clear screens for every task: a large sound level reading, three profiles with different weightings side by side, LN statistics, time history, a summary of Leq, L10, L50, L90, Max, Min and SD, GPS position and time, and 1/1 or 1/3 octave spectra.

Class 1 or Class 2?

BSWA 308 (Class 1) has tighter tolerances, a wider frequency range and lower noise floor. Choose it for environmental noise assessment, legal measurements and laboratory work. BSWA 309 (Class 2) covers 20 Hz–12.5 kHz with a 40 mV/Pa Class 2 microphone. Choose it for workplace noise surveys, construction site noise, product quality checks and routine measurements. Both share the same features and software, so you can mix them in one measurement team. Ask us which class fits your application. เลือก Class 1 (BSWA 308) สำหรับงานวัดเสียงสิ่งแวดล้อมและงานตามกฎหมาย หรือ Class 2 (BSWA 309) สำหรับงานสำรวจเสียงในโรงงานและตรวจคุณภาพผลิตภัณฑ์
